Our range of large industrial RO systems is divided into 3 categories: 2000 PPM, 6000 PPM, and 10000 PPM.
This is the range for treating water up to 2000 PPM, which covers the vast majority of water considered drinkable.
Installation & Maintenance
Installation
Documentation and commissioning
Documents for these industrial RO systems are available in PDF format in the Documents and Downloadssection. There you will find the data sheets and manuals needed for installation and commissioning.
Maintenance
Recommended replacement intervals
Filters and membranes must be replaced regularly to maintain the filtration performance of your system.
| Consumable | Suggested interval | Product |
| 10-micron PP filter | Every 3 months For continuous use, 24 h/day |
Discover |
| Vontron 4040 membranes | Every 2 to 3 years For continuous use, 24 h/day |
Discover |
Other consumables available: hypochlorite, anti-scalant, and 25-micron pre-filter. They are available on request by email.
Warranty
Manufacturer warranty and parts availability
The manufacturer warranty is 2 years and covers the entire system under normal use of the equipment.
After the warranty period expires, we also commit to providing you with spare parts at reasonable prices to make repairs easier and extend the life of your system.
Specifications
Technical specifications
General configuration of the industrial RO system
| Specifications | Values |
|---|---|
| Operating pressure | 6 to 12 bar |
| Salt rejection ratio | 99% |
| Pressure gauge | Glycerin-filled pressure gauge |
| Flowmeters | Inlet and outlet flowmeters |
| Display | Real-time display of filtered water conductivity |
| Control panel | 7" OMRON digital control panel |
| Pump | Lowara vertical pump (Grundfos available at extra cost if needed) |
| Frame | Stainless steel frame |
| Tubing | High-strength PVC tubing (stainless steel available at extra cost) |
| Membrane housings | GRP (glass-fiber reinforced plastic) |
| Power supply | 400V three-phase – 50Hz |
| Recovery rate | 50 to 75% – 1 liter of wastewater for every 1 to 3 liters of RO water |
| Normal operating condition | 2,000 ppm / 3,125 μS/cm |
⚠️ Watch out for chlorides
The standard 2,000 and 6,000 PPM versions are designed for a maximum chloride level of 500 mg/l. For levels between 500 and 1,100 mg/l, the pump must be replaced with a 316 stainless steel model, at an extra cost of about €1,000 excl. VAT (custom quote). Above 1,100 mg/l, you must choose the 10,000 PPM.
Available models and capacities
From 1,200 to 18,000 liters per hour
| Model | Membranes | Capacity | m³/day | Pump power | Inlet / outlets | Dimensions | Weight | Optional sand filter |
|---|---|---|---|---|---|---|---|---|
| OI3240 | 6 × ULP11-4040 | 1,200 l/h | 29 | 3 HP | 1"1/4 | 300 × 90 × 160 cm | 250 kg | A670130 – 100,kg silica sand / 39,kg anthracite, TM67 valve – €892 excl. VAT |
| OI2180 | 2 × ULP12-8040 | 1,800 l/h | 43 | 3.5 HP | 1"1/2 | 275 × 100 × 170 cm | 450 kg | A750200 – 175,kg silica sand / 75,kg anthracite, TM75 valve – €1,853 excl. VAT |
| OI3180 | 3 × ULP12-8040 | 2,500 l/h | 60 | 4.5 HP | 1"1/2 | 275 × 100 × 170 cm | 475 kg | A750340 – 250,kg silica sand / 100,kg anthracite, TM75 valve – €2,139 excl. VAT |
| OI2280 | 4 × ULP12-8040 | 4,000 l/h | 96 | 6 HP | 1"1/2 | 300 × 110 × 170 cm | 500 kg | A750340 – 250,kg silica sand / 100,kg anthracite, TM75 valve – €2,139 excl. VAT |
| OI3280 | 6 × ULP12-8040 | 5,500 l/h | 132 | 6 HP | 1"1/2 | 300 × 110 × 170 cm | 600 kg | A750750 – 550,kg silica sand / 200,kg anthracite, TM75 valve – €3,688 excl. VAT |
| OI4280 | 8 × ULP12-8040 | 7,600 l/h | 182 | 8 HP | 2" | 300 × 110 × 170 cm | 700 kg | A750500 × 2 – 750,kg silica sand / 300,kg anthracite, TM75 valve – €5,814 excl. VAT |
| OI3380 | 9 × ULP12-8040 | 9,000 l/h | 216 | 8 HP | 2" | 300 × 110 × 170 cm | 750 kg | A750500 × 2 – 750,kg silica sand / 300,kg anthracite, TM75 valve – €5,814 excl. VAT |
| OI4380 | 12 × ULP12-8040 | 12,000 l/h | 288 | 12 HP | 2" | 300 × 110 × 170 cm | 900 kg | A750750 × 2 – 1,100,kg silica sand / 400,kg anthracite, TM75 valve – €7,376 excl. VAT |
| OI6380 | 18 × ULP12-8040 | 18,000 l/h | 432 | 18 HP | 2"1/2 | 300 × 160 × 170 cm | 1,200 kg | A961400 × 2 – 2,050,kg silica sand / 750,kg anthracite, TM96 valve – €20,490 excl. VAT |
Scroll the table horizontally on mobile to view all specifications.
Close-up of the center section of the industrial RO system
Electrical
System power supply
Power supply: 380V three-phase
Documents
Documents and downloads
Technical documentation and installation manuals
Assembly sheet
Review the main assembly and connection instructions for industrial RO systems.
Download the assembly sheetModel OI3240 – 1200 L/h
Documentation specific to the model equipped with 4040 membranes
Installation manual
Installation and commissioning manual specific to model OI3240 – 1200 L/h.
Download the installation manualOther industrial RO system models
Documentation for models equipped with 8040 membranes
Data sheet
Technical specifications for the other models in the range equipped with 8040 membranes.
Download the data sheetInstallation manual
Installation and commissioning manual for the other industrial RO system models in the range.
Download the installation manual
